Multitube cyclone inline separator

    A multitube cyclone inline separator causes a wet gas flowstream to be divided between a number of cyclone tubes. As the gas stream enters a tube, it encounters a spin generator. The spin generator is a stationary device consisting of a hollow core and a radial arrangement of curved blades that divert the gas stream into a rotating flow pattern. In the tube downstream of the spin generator, liquid is separated from the gas by being slung out against the tube wall by centrifugal force. Near the end of each tube, the liquid film encounters a peripheral gap in the tube wall. This gap allows the liquid to be pulled out of the tube into the annular space around the tubes, where it falls to the bottom and is discharged under level control. The demisted gas stream continues through the tube, then recombines with that of the other tubes.
